AT8402 User Guide
3.2.6
Front Panel Elements
Figure 3-5: Front Panel of the RTM8400
GE2
GE1
PPC FE Port: Upper LED (green) displays Link/Activity, lower LED (yellow)
displays Speed
RJ45 PPC RS232 Interface
External 4x SAS Connector
DB9 PPC RS232 Interface
GbE Port 1: Upper LED (green/yellow) displays Speed, lower LED (green)
displays Link/Activity
FE
RS232
GbE Port 2: Upper LED (green/yellow) displays Speed, lower LED (green)
displays Link/Activity
