AT8402 Hardware Description
Page 3 - 21 AT8402 User Guide
Table 3-18: Jumper Settings ( • Default Setting)
FWPD - Flash Write Enable
Write Enable in
• Write Protect out
IPMC0 - Front Board IPMI Override
ShMC Bypass in
• Normal Operation out
IPMC1 - AMC IPMI Override
ShMC Bypass in
• Normal Operation out
IPMC2 - PCIe E-Keying Override
ShMC Bypass in
• Normal Operation out
JTAG_AMC - AMC JTAG Integration
Included in JTAG Chain in
• Excluded from JTAG Chain out
JTAG_IPMC - IPMC JTAG
Restrict JTAG to IPMC in
• Normal JTAG Operation out
