AT8402 Hardware Description
Page 3 - 11 AT8402 User Guide
11 Fabric PCI Express Switch Port 8, Lane 7
12 Extended RTM, AMC_B2_P12
13 Extended RTM, AMC_B2_P13
14 Extended RTM, AMC_B2_P14
15 Extended RTM, AMC_B2_P15
17 Extended RTM, AMC_B2_P17
18 Extended RTM, AMC_B2_P18
19 Extended RTM, AMC_B2_P19
20 Extended RTM, AMC_B2_P20
TCLKA Clock From Backplane
TCLKB Clock To Backplane
TCLKC Clock From Backplane
TCLKD Clock To Backplane
FCLKA Clock PCIe Reference Clock
* Configured for SAS Connect
** Configured for Direct AMC Connect
Table 3-11: AMC B3 Channel Assignment
Channel Region Connection
0 GbE GbE Switch 0/11
1 GbE GbE Switch 0/12
2 SAS/SATA
SAS Expander Port 0*
AMC B1 Channel 3**
3 SAS/SATA -
4 Fabric PCI Express Switch Port 1, Lane 0
5 Fabric PCI Express Switch Port 1, Lane 1
6 Fabric PCI Express Switch Port 1, Lane 2
7 Fabric PCI Express Switch Port 1, Lane 3
8 Fabric -
9 Fabric -
10 Fabric -
11 Fabric -
12 Extended RTM, AMC_B3_P12
13 Extended RTM, AMC_B3_P13
14 Extended RTM, AMC_B3_P14
15 Extended RTM, AMC_B3_P15
17 Extended RTM, AMC_B3_P17
18 Extended RTM, AMC_B3_P18
19 Extended RTM, AMC_B3_P19
20 Extended RTM, AMC_B3_P20
TCLKA Clock From Backplane
TCLKB Clock To Backplane
Table 3-10: AMC B2 Channel Assignment (Continued)
Channel Region Connection
