AT8402 Hardware Description
Page 3 - 15 AT8402 User Guide
The Zone 3 connectors have the following pin assignments.
Table 3-13: J30 Assignment
J30 ROW A AB ROW B ROW C CD ROW D
1 N.C. GND N.C. N.C. GND N.C.
2 PROD_IO0 GND PROD_IO1 N.C. GND N.C.
3 12V GND 3V3_SUS SMB_SCL GND SMB_SDA
4 PROD_IO2 GND PLD_DOUT PLD_CLOCK GND PLD_DIN
5 JTAG_TDO GND TEST_JIG# N.C. GND PROD_IO3
6 JTAG_TDI GND 12V N.C. GND N.C.
7 JTAG_TCK GND PROD_IO4 N.C. GND N.C.
8 JTAG_TMS GND JTAG_TRST# N.C. GND N.C.
9 SP_RI GND SP_DTR SP_CTS GND SP_TX#
10 SP_RTS GND SP_RX# SP_DSR GND SP_DCD
J30 ROW E EF ROW F ROW G GH ROW H
1 MNG_LAN_DA- GND MNG_LAN_DA+ STOR0_RX- GND STOR0_RX+
2 MNG_LAN_DB- GND MNG_LAN_DB+ STOR0_TX- GND STOR0_TX+
3 N.C. GND N.C. STOR1_RX- GND STOR1_RX+
4 N.C. GND N.C. STOR1_TX- GND STOR1_TX+
5 N.C. GND GLAN_AB_CT STOR2_RX- GND STOR2_RX+
6 MNG_LAN_CT GND 12V STOR2_TX- GND STOR2_TX+
7 N.C. GND N.C. STOR3_RX- GND STOR3_RX+
8 N.C. GND SMB_ALRT# STOR3_TX- GND STOR3_TX+
9 N.C. GND N.C. N.C. GND N.C.
10 N.C. GND N.C. N.C. GND N.C.
