AT8402
Hardware Description
Page 3 - 16
AT8402 User Guide
Table 3-14: J31 Assignment
J31
ROW A
AB
ROW B
ROW C
CD
ROW D
1
RTM_GE1_DA+
GND RTM_GE1_DA-
RTM_GE1_DB+
GND RTM_GE1_DB-
2
RTM_GE2_DA+
GND RTM_GE2_DA-
RTM_GE2_DB+
GND RTM_GE2_DB-
3
N.C.
GND N.C.
N.C.
GND N.C.
4
N.C.
GND N.C.
N.C.
GND N.C.
5
AMC_B1_P12_TX+
GND AMC_B1_P12_TX-
AMC_B1_P12_RX+
GND AMC_B1_P12_RX-
6
AMC_B1_P14_TX+
GND AMC_B1_P14_TX-
AMC_B1_P14_RX+
GND AMC_B1_P14_RX-
7
AMC_B1_P17_TX+
GND AMC_B1_P17_TX-
AMC_B1_P17_RX+
GND AMC_B1_P17_RX-
8
AMC_B1_P19_TX+
GND AMC_B1_P19_TX-
AMC_B1_P19_RX+
GND AMC_B1_P19_RX-
9
AMC_B2_P17_TX+
GND AMC_B2_P17_TX-
AMC_B2_P17_RX+
GND AMC_B2_P17_RX-
10
AMC_B2_P19_TX+
GND AMC_B2_P19_TX-
AMC_B2_P19_RX+
GND AMC_B2_P19_RX-
J31
ROW E
EF
ROW F
ROW G
GH
ROW H
1
RTM_GE1_DC+
GND RTM_GE1_DC-
RTM_GE1_DD+
GND RTM_GE1_DD-
2
RTM_GE2_DC+
GND RTM_GE2_DC-
RTM_GE2_DD+
GND RTM_GE2_DD-
3
N.C.
GND N.C.
N.C.
GND N.C.
4
N.C.
GND N.C.
N.C.
GND N.C.
5
AMC_B1_P13_TX+
GND AMC_B1_P13_TX-
AMC_B1_P13_RX+
GND AMC_B1_P13_RX-
6
AMC_B1_P15_TX+
GND AMC_B1_P15_TX-
AMC_B1_P15_RX+
GND AMC_B1_P15_RX-
7
AMC_B1_P18_TX+
GND AMC_B1_P18_TX-
AMC_B1_P18_RX+
GND AMC_B1_P18_RX-
8
AMC_B1_P20_TX+
GND AMC_B1_P20_TX-
AMC_B1_P20_RX+
GND AMC_B1_P20_RX-
9
AMC_B2_P18_TX+
GND AMC_B2_P18_TX-
AMC_B2_P18_RX+
GND AMC_B2_P18_RX-
10
AMC_B2_P20_TX+
GND AMC_B2_P20_TX-
AMC_B2_P20_RX+
GND AMC_B2_P20_RX-
