Kontron AT8940 - Manual (Page 67)

Software Setup
52 AT8910/AT8940
www.kontron.com
The image will be copied including the configuration settings currently stored for active image
8 In case of problems with booting the system, last working image (now the backup image) will
automatically be copied and used for next time boot. This procedure restores previous system behavior.
9 It is recommended to copy active image to backup image to have a fully redundant system
(BASE Ethernet) #copy active backup
Copying active image to backup image
(BASE Ethernet) #
The image will be copied including the configuration settings currently stored for active image
5.3 Updating IPMI
Updating the IPMI firmware is done with the "copy" command. In case that the update procedure fails or the
update image is corrupted, the PM will be able to restart by means of its rollback functionality.
The IPMI firmware package file is provided in tar format and is stored in the data/update directory of the
release directory tree.
(BASE Ethernet) #copy tftp://192.168.50.5/t5310-ipmi-BETA-1.02.tar ipmi
Mode........................................... TFTP
Set Server IP.................................. 192.168.50.5
Path........................................... ./
Filename....................................... t5310-ipmi-BETA-1.02.tar
Data Type...................................... FW Update
Destination Filename........................... ipmi
Management access will be blocked for the duration of the transfer
Are you sure you want to start? (y/n) y
TFTP Firmware transfer starting...
Firmware update successful...
5.4 Updating the 10G PHY Firmware
Updating the 10G PHY firmware is done with the "copy" command.
There are two PHYs that can be updated, one for base and one for extension Fabric
• t5310-phy-BETA-1.02.tar (for base PHY BCM8727)
• t5310-phyfabric-BETA-1.02.tar (for fabric PHY BCM8727)
The update packages for both10G PHYs are provided as tar-files and are stored in the data/update path of the
release directory tree.
