Hardware Management
47
www.kontron.com
4.3.3.2
Health Sensor Aggregation
The following table shows the sensors involved in the health sensor aggregation. The Health Sensor is an
aggregation of all analog sensors and is asserted when at least one of the listed sensors report an asserted
offset for critical or non-recoverable state.
Table 4-35: Health Sensor Aggregation Table
51
FRU Pwr Denied
CDh (OEM FRU Power Denied)
Event Type: 03h (digital discrete)
52
FRU MngtPwr Fail
D2h (OEM FRU Management Power)
Event Type: 03h (digital discrete)
53
FRU0 Agent
C5h (OEM FRU Info Agent)
Event Type: 0Ah (generic discrete)
54
FRU1 Agent
C5h (OEM FRU Info Agent)
Event Type: 0Ah (generic discrete)
55
EventRcv ComLost
1Bh (Cable Disconnect)
Event Type: 03h (digital discrete)
56
IPMC Reboot
24h (Platform Alert)
Event Type: 6Fh (Sensor-specific discrete)
57
IPMC FwUp
C7h (OEM IPMC Firmware Upgrade)
Event Type: 6Fh (Sensor-specific discrete)
58
IPMC Storage Err
28h (Management Subsystem Health)
Event Type: 6Fh (Sensor-specific discrete)
59
IPMC SEL State
10h (Event Logging Disable)
Event Type: 6Fh (Sensor-specific discrete)
60
Jumper Status
D3h (OEM Jumper)
Event Type: 6Fh (Sensor-specific discrete)
61
IPMI Info-1
C0h (OEM Firmware Info)
Event Type: 70h (OEM)
62
IPMI Info-2
C0h (OEM Firmware Info)
Event Type: 70h (OEM)
Sensor ID string
Temp Inlet
Temp Outlet-1
Temp Outlet-2
Temp ADT7461
Temp BCM5684X
Temp BCM54680-1
Temp BCM54680-2
Temp INTEL82580
Temp Diode A4
Vcc +1.2V SUS
Vcc +2.5V SUS
Vcc +3.3V SUS
Vcc +5V SUS
Vcc +12V
Vcc +0.75Vref
Vcc +0.75Vtt
Vcc +1.0V
Vcc +1.025V A
Vcc +1.025V D
Vcc +1.05V
ID
Sensor Name
Sensor Class
Description (Sensor Type, Event Trigger)
