Product Description
8
www.kontron.com
1.6.2
System Manager
• Support for basic and micro COM Express Modules with Type 1 connector, according COMExpress 0 R1.0
• Management connection to System Manager via RS232 front RJ45.
• Basic use SuperIO LPC to UART Bridge
• UART switched through FPGA
• Management connection to System Manager using front 10/100/1000Base-T RJ45 management port.
• Front panel USB port
• Support of COMExpress modules up to 30W
• Additional Ethernet Connection to Base IF and redundant HUB via Dual Ethernet Controller Intel 82580DB
• 1000Base-BX to Base Switch
• 1000Base-BX to Update Channel
• Support for JEDEC SerialATA MO-297 SSD, Port 0 and Port 2
• Support for RTM SATA applications, Port 1 and Port 3
• Support of up to 2 eUSB Flash Modules
