Hardware Management
46
www.kontron.com
10
Temp BCM54680-2
01h (Temperature)
Event Type: 01h (Threshold)
11
Temp INTEL82580
01h (Temperature)
Event Type: 01h (Threshold)
12
Temp Diode A4
01h (Temperature)
Event Type: 01h (Threshold)
13
Temp DIMM
01h (Temperature)
Event Type: 01h (Threshold)
14
Vcc +1.2V SUS
02h (Voltage)
Event Type: 01h (Threshold)
15
Vcc +2.5V SUS
02h (Voltage)
Event Type: 01h (Threshold)
16
Vcc +3.3V SUS
02h (Voltage)
Event Type: 01h (Threshold)
17
Vcc +5V SUS
02h (Voltage)
Event Type: 01h (Threshold)
18
Vcc +12V
02h (Voltage)
Event Type: 01h (Threshold)
19
Vcc +0.75Vref
02h (Voltage)
Event Type: 01h (Threshold)
20
Vcc +0.75Vtt
02h (Voltage)
Event Type: 01h (Threshold)
21
Vcc +1.0V
02h (Voltage)
Event Type: 01h (Threshold)
22
Vcc +1.025V A
02h (Voltage)
Event Type: 01h (Threshold)
23
Vcc +1.025V D
02h (Voltage)
Event Type: 01h (Threshold)
24
Vcc +1.05V
02h (Voltage)
Event Type: 01h (Threshold)
25
Vcc +1.2V
02h (Voltage)
Event Type: 01h (Threshold)
26
Vcc +1.5V
02h (Voltage)
Event Type: 01h (Threshold)
27
Vcc +1.8V
02h (Voltage)
Event Type: 01h (Threshold)
28
Vcc +2.5V
02h (Voltage)
Event Type: 01h (Threshold)
29
Vcc +3.3V
02h (Voltage)
Event Type: 01h (Threshold)
30
Vcc +5V
02h (Voltage)
Event Type: 01h (Threshold)
31
Icc 12v
03h (Current)
Event Type: 01h (Threshold)
32
RTM Power
03h (Current)
Event Type: 01h (Threshold)
33
-48V Feed A Fail
08h (Power Supply)
Event Type: 6Fh (Sensor-specific discrete)
34
-48V Feed B Fail
08h (Power Supply)
Event Type: 6Fh (Sensor-specific discrete)
35
-48V Fuse Fail
A fuse failure only can be detected when both power
feeds are present and valid.
36
Power State
D1h (OEM Power State)
Event Type: 6Fh (Sensor-specific discrete)
37
Board Reset
CFh (OEM Reset)
Event Type: 03h (digital discrete)
38
POST Value
C6h (OEM Post)
Event Type: 6Fh (Sensor-specific discrete)
39
POST Error
C6h (OEM Post)
Event Type: 6Fh (Sensor-specific discrete)
40
Boot Error
1Eh (OEM Boot Error)
Event Type: 6Fh (Sensor-specific discrete)
41
Diag Status
C9h (OEM Diagnostic Status)
Event Type: 6Fh (Sensor-specific discrete)
42
Fwupg Status
CAh (OEM Firmware Update)
Event Type: 6Fh (Sensor-specific discrete)
43
IPMI Watchdog
23h (IPMI Watchdog 2)
Event Type: 6Fh (Sensor-specific discrete)
44
FW Ver Change
2Bh (Version Change)
Event Type: 6Fh (Sensor-specific discrete)
45
Health Error
24h (Platform Alert)
Event Type: 03h (digital discrete)
46
IPMB0 Link State
F1h (PICMG Physical IPMB-0)
Event Type: 6Fh (Sensor-specific discrete)
47
FRU0 IPMBL State
C3h (OEM IPMB-L Link State)
Event Type: 6Fh (Sensor-specific discrete)
48
FRU1 IPMBL State
C3h (OEM IPMB-L Link State)
Event Type: 6Fh (Sensor-specific discrete)
49
FRU Over Icc
CBh (OEM FRU Over Current)
Event Type: 6Fh (Sensor-specific discrete)
50
FRU Sensor Error
CCh (OEM FRU Sensor Discovery)
Event Type: 03h (digital discrete)
ID
Sensor Name
Sensor Class
Description (Sensor Type, Event Trigger)
