4.3.2.9 OemApGetNvSensConfig
Table 4-29:Command OemApGetNvSensConfig
4.3.2.10 OemApFpgaWriteRead
Table 4-30:Command OemApFpfaWriteRead
11 UNR Threshold
12 UCR Threshold
13 UNC Threshold
14 LNR Threshold
15 LCR Threshold
16 UNC Threshold
17 Positive Hysteresis
18 Negative Hysteresis
Response Data 1 Completion Code
Byte Data Field
Request Data 1
2
3
4
5
Sensor Config Entry Number: 0..17
Response Data 1 Completion Code
2 Sensor Number
3..4 Assertion Mask
5..6 De-assertion Mask
7 UNR Threshold
8 UCR Threshold
9 UNC Threshold
10 LNR Threshold
11 LCR Threshold
12 UNC Threshold
13 Positive Hysteresis
14 Negative Hysteresis
Byte Data Field
Request Data 1
2
3
4
Byte Data Field
