Hardware Management
42 AT8910/AT8940
www.kontron.com
4.3.2.7 OemApGetNvData
Table 4-27:Command OemApGetNvData
4.3.2.8 OemApSetNvSensConfig
Table 4-28:Command OemApSetNvSensConfig
84h
0
1 0h
0h
ETX module configuration
Byte0:
[0]
0b = module not is present
1b = module is present
[1..7] reserved
Byte1:
ETX Module power draw in Watt
85h 0..15
07h 67h
FFh FFh
FFh FFh
FFh FFh
FFh FFh
FFh FFh
FFh FFh
FFh FFh
Thermal Trip Configuration for
n sensors
Byte 0+(n*2):
Number #n
FFh=UNDEF
Byte 1+(n*2):
Threshold #n
FFh=UNDEF
Byte Data Field
Request Data 1
2
3
4
5
NV Data Param ID
Response Data 1 Completion Code
2..N Raw data
Byte Data Field
Request Data 1
2
3
4
5
Sensor Config Entry Number: 0..17
6 Sensor Number
7..8 Assertion Mask
9..10 De-assertion Mask
Table ID Byte Offset Default Value Description
