Board Features
17 AT8910/AT8940
www.kontron.com
Table 2-4:Fabric Switch Port Mapping AT8940
BCM56846
WarpCore Group BCM56846
WarpCore Lane SerDes Operation
Mode Speed Connected to
0
0
0 1
XFI 4x 1GbE or 4x 10GbE Front uplinks
1 2
2 3
3 4
1
0 5
KR4 40GbE RTM QSFP+ FI1
1 6
2 7
3 8
2
0 9
XAUI/KR4 10/40 GbE FC# 15
1 10
2 11
3 12
3
0 13
XAUI/KR4 10/40 GbE FC# 13
1 14
2 15
3 16
4
0 17
XAUI/KR4 10/40 GbE FC# 6
1 18
2 19
3 20
1
5
0 21
XAUI/KR4 10/40 GbE FC# 5
1 22
2 23
3 24
6
0 25
XAUI/KR4 10/40 GbE FC# 4
1 26
2 27
3 28
7
0 29
XAUI/KR4 10/40 GbE FC# 2
1 30
2 31
3 32
8
0 33
XAUI/KR4 10/40 GbE FC# 3
1 34
2 35
3 36
