Hardware Management
40 AT8910/AT8940
www.kontron.com
4.3.2.2 OemApGetControlState
Table 4-20:Command OemApGetControlState
Table 4-21:Control States
4.3.2.3 OemApGetFirmwareSysUpTime
Table 4-22:Command OemApGetFirmwareSysUpTime
4.3.2.4 OemApFormatStorage
Table 4-23:Command OemApFormatStorage
Byte Data Field
Request Data 1 Control ID
Response Data 1 Completion Code
2 Control State
Control ID Control State
0 - Flash Select
0 - Select Flash Image 0 (valid for next boot)
1 - Select Flash Image 1 (valid for next boot)
1 - Guest OS reset NA
2 - ETX module controll NA
3 - Ethernet Clock Source Select
0 = Local Oscillator Clock is enabled
1 = Base Interface Sync_E_Clock is enabled
4 - SOL source selection
Selected Serial interface for SOL
1 - ETX module (default)
2 - Guest#0
3 - Guest#1
Byte Data Field
Request Data 1
2
3
4
Response Data 1 Completion Code
2..5 System Up-Time in seconds
Byte Data Field
Request Data 1
2
3
4
Response Data 1 Completion Code
