VMP3 NetBootLoader
ID 29230, Rev. 01 © 2005 Kontron Modular Computers GmbH Page 5 - 7
29230
.01.UG.VC.050727/091438
P R E L I M I N A R Y
5.3.3.2 tftp/ftp Server Access
The NetBootLoader provides various functions for interfacing with either a tftp or ftp server.
The tftp server access is a simple method of acquiring a userimage from a remote source. Its
primary use is to download a single executable userimage from a given source. For example,
once an application has been programmed it would be possible to store it at a remote location
where it then would be available for remote booting of an VMP3 via the Ethernet port FCC1
(FE).
The ftp server commands provide various functions consistent with interfacing with such a
server.
The following table provides an overview of available tftp/ftp server functions.
5.3.4 FLASH Operation
The NetBootLoader provides various functions for performing operations with Flash memory.
The following table provides an overview of available FLASH operation functions.
Table 5-3: tftp/ftp Server Commands
CMD TITLE ALIAS FUNCTION REMARKS
BYE - Terminate session with ftp server
CD Change
Directory
Change ftp server directory
GET - Download a file from ftp server Only for executable applications.
Data buffer is target.
LOGIN - Login to ftp server
LS List Directory List ftp server directory Lists contents of directory.
PUT - Upload a file to ftp server Data buffer is source.
PWD Print Working
Directory
Display current ftp server directory Lists name of directory
TFTP - Download a file from tftp server
Table 5-4: FLASH Operation Commands
CMD TITLE ALIAS FUNCTION REMARKS
CLONE - Program NetBootLoader to FLASH Uses data buffer or socket as source
LF Load FLASH Program application to FLASH Uses data buffer as source
SF Store FLASH Reads FLASH to data buffer Uses data buffer as target
