VMP3

Configuration

ID 29230, Rev. 01

© 2005 Kontron Modular Computers GmbH

Page 4 - 11

29230

.01.UG.VC.050727/091435

P R E L I M I N A R Y

4.2.9

Board Logic / Revision Register

The Board Revision Register provides the hardware (BRn) and logic (LRn) status of the board.
It is set at the factory and starts with the value 0x00 for the initial board prototypes and will be
incremented with each redesign / logic release.

Table 4-10:Board Logic / Revision Register

REGISTER NAME

BOARD LOGIC/REVISION

ACCESS

ADDRESS

0xFFFF A009

R

BIT POSITION

MSB

7

6

5

4

3

2

1

0

LSB

CONTENT

LR3

LR2

LR1

LR0

BR3

BR2

BR1

BR0

DEFAULT

n/a

n/a

n/a

n/a

n/a

n/a

n/a

n/a
