VMP3 VMP1-IO1 Module
ID 29230, Rev. 01 © 2005 Kontron Modular Computers GmbH Page B - 11
29230
.01.UG.VC.050727/091443
P R E L I M I N A R Y
B.8 Jumper Setting
The jumper settings of the IO1 module depend on the module’s position relative to the VMP3
and other modules, if any.
Table B-4: IO1 Jumper Settings for Different Module Positions
IDSEL Clock GNT# REQ#
J12 J11 J10 J1 J2 J3 J4 J5 J6 J7 J8 J9
Position 1 Set Open Open Set Open Open Set Open Open Set Open Open
Position 2 Open Set Open Open Set Open Open Set Open Open Set Open
Position 3 Open open Set Open Open Set Open Open Set Open Open Set
Note:
Position 1 refers to the settings applicable when 1 module (IO1 or other) is
attached to the VMP3.
Position 2 refers to the settings applicable when 2 modules (IO1 or other) are
attached to the VMP3.
Position 3 refers to the settings applicable when 3 modules (IO1 or other) are
attached to the VMP3.
Important!:
Position 3 has not yet been tested and approved and is not recommended for
use with this issue of the manual.
