Page 28: Introduction vmp3
Introduction
VMP3
Page 1 - 8
© 2005 Kontron Modular Computers GmbH
ID 29230, Rev. 01
29230
.01.UG.VC.050727/091408
P R E L I M I N A R Y
1.3.3
Board Layout
Figure 1-3: VMP3 Board (Front View Without E²Brain™ Module)
Figure 1-4: VMP3 Board (Front View With E²Brain™ Module)
J5B
J5A
J6
J7
D1
D2
J8
J9
J12
J11
J10
PCI
to
VME
Bridge
