VSBC-32 Serial Interface Piggybacks
ID 21168, Rev. 04 Page B - 3 © PEP Modular Computers GmbH
B. Serial Interface Piggybacks
B.1 General
The serial interface (SI) piggybacks described herein adapt the multi-protocol serial
channels of the 68EN360 controller chip to one of the following physical interfaces:
• 10Base2 (thin or cheapernet) Ethernet,
• 10Base5 (AUI) Ethernet,
• 10BaseT (twisted pair) Ethernet,
• RS-232 modem compatible,
• RS485 optoisolated (PROFIBUS),
and are available for a wide variety of PEP CPU boards.
Table B-1: SI Piggyback Types and Configurations
Type
Configuration
Standard Connectors
SI-10B2
10Base2
(Ethernet: thin)
RG58
(Coaxial)
SI-10B5
10Base5
(AUI)
D-Sub
(15-pin)
SI-10BT
10BaseT
(Twisted-pair)
RJ45
(8-pin)
SI-PB232
RS-232
(Modem interface)
2 x RJ45
(8-pin)
SI-PB485-ISO
RS485
(Optoisolated, 2 wire half-duplex,
PROFIBUS)
D-Sub
(9-pin)
