1.3.3 Board Layouts
Figure 1-3: VSBC-32(E) Board Diagram (front)]
FLASH/EPROM:
Upper Data: D8-D15, even Byte addresses
Lower Data: D0-D7, odd Byte addresses
BDM: Background Debug Mode.
SRAM
FLASH/EPROM
(Upper Data)
1 16
17 32
FLASH/EPROM
(Lower Data)
1 16
17 32
1 6
7 12
BDM
CPU / Serial
Communications
Controller
ST2B
ST2C
1 7 SI Piggyback
1
49
2
50
BU3
1
49
2
50
BU4
Memory Piggyback
EEPROM
ST2A
1 7
J14
3
1
2
J13
3
1
2
J11 J12
J9 J10
J6
