Ets lindgren – ETS-Lindgren 2181 Turntable User Manual
Page 44
28
8
13
14
5
18
19
18
19
34
22
35
3
26
29
7
17
4
23
27
11
10
24
20 21 32
9
16 33
2
1
18
19
18
19
18
19
18
19
29
30
6 25
12
15
31
CASTER SPACER STRUT SHOWN
REF ONLY
GAUGE PLATE ASSY SHOWN
REF ONLY
OUTER GAUGE PLATE SHOWN
REF ONLY
BASE PLATE SHOWN
REF ONLY
BEARING SHOWN
REF ONLY
ITEM#
11317
9/QTY
.
PART#
DESCRIPTION
36
1
920250 LABEL,ETS-LINDGREN,3.75 X 1.75,WHT BKGRD (N/S)
35
8
910930 SCREW,10-32 X 3/8,PHIL,FLAT,SS
34
18
910923 BOLT,1/2-13 X 3,SH,FLAT,SS
33
288
910714 SCREW,6-32 X 1/4,PHIL,BIND,TAPTITE
32
160
910652 SCREW FH PHL ZN TAPTITE 6-32 X 3/8 (N/S)
31
12
910536 SCREW,1/2-13 X 1 1/2,SH,FLAT,ZN
30
272
910373 SCREW,5/16-18 X 1,SH,FLAT,SS
29
120
910369 SCREW,5/16-18 X 1-1/2,SH,FLAT,STL,ZINC
28
8
910368 SCREW,5/16-18 X 3/4,FLAT,SH,ZN
27
192
910367 NUT,1/2-13,HEX,SERRATED FLANGE,ZN
26
4
910241 SCREW,8-32 X 3/8,PHIL,FLAT,SS
25
24
910173 SCREW,6-32 X 3/8,PHIL,FLAT,SS
24
24
891125 CASTER 12" WHEEL,RIGID,15.50" HEIGHT
23
192
890238 SCREW LEVELING 1/2-13 X 3 SQ HD CU
22
2
880352 PIN,CLEVIS,SS,1/2"O.D. X 2.0" LONG
21
52
760275 ASSY,BRUSH,/HOLDER,4',TT CONTACT BRUSH
20
12
705436 FLOOR FLANGE,TURNTABLE,2181-5.0m,AL
19
6
113172 TOP,SECTION2,TURNTABLE,2181-5.0
18
6
113171 TOP,SECTION1,TURNTABLE,2181-5.0
17
12
113170 TIE PLATE,TOP,TURNTABLE,2181-5.0
16
24
113169 CONTACT STRIP,BRUSH,TURNTABLE
15
1
112350 TOP,SECTION 4,TURNTABLE,2181-3.0
14
1
112349 TOP,SECTION 3,TURNTABLE,2181-3.0
13
1
112348 TOP,SECTION 2,TURNTABLE,2181-3.0
12
1
112347 TOP,SECTION 1,TURNTABLE,2181-3.0
11
48
112343 FLOOR PLATE,OUTER,TURNTABLE,2181-3.0
10
24
112342 SPACER,OUTER,CASTER,TURNTABLE,2181-3.0
9
12
112341 STIFFENER,OUTER,TURNTABLE,2181-3.0
8
1
112215 COVER,CENTER,TOP,2181 TURNTABLES
7
16
112204 TIE PLATE,BASE PLATE,2181 TURNTABLE
6
12
110405 CONTACT FLAT,BRUSH,TURNTABLE
5
6
110059 PLUG,HOLE,TABLE TOP
4
18
109960 SPACER,2" OD X .51 ID X 1.50
3
1
108925 COVER,ACCESS
2
6
105813 TAB,TOP,2087
1
12
105053 PLATE,DRIVE,2081-2M/4M
SUB-ASSY,TOP,TURNTABLE,2181-5.0
1:12
113179
1
1
1
6/11/08
X.XX
X.XXX
.005
.015
.5
NONE
REF DRAWING
ECN
REV
APPROVED
REVISIONS
DESCRIPTION
DATE
DO NOT SCALE DRAWING
ETS LINDGREN
SIZE
THIRD ANGLE PROJECTION
ENGINEERING
INITIAL
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES
REMOVE ALL BURRS AND SHARP EDGES
SURFACE FINISH 63 RMS OR BETTER
FINISH
TOLERANCES ARE:
DECIMALS
±
±
±
ANGLES
DRAFTING
PERMISSION OF ETS LINDGREN
IS PROHIBITED.
ANY DUPLICATION OF THIS
PROPRIETARY INFORMATION
WITHOUT EXPRESS WRITTEN
DOCUMENT, WHOLE OR IN PART,
DATE
TITLE
OF
SHEET
DWG. NO.
An ESCO Technologies Company
SCALE
D
TM
REV.
1
INITIAL BUILD
-
RBG
