6. Continue mounting until all screws are installed. Some screws may fall
between the floor panel joints. Try to position the flanges, making sure as
few screws hit these points as possible, and making sure that the first or
last hole in the flange is not too close to one of these joints. Trim the top
floor joint strips to fit up against the flange.
Floor Flange Installation in a Concrete Pit
Installing in a concrete pit is the same as a paneled floor, with the exception of
the mounting hardware. Instead of the #14 x 1-in square socket flat head screws,
use 1/4 x 1-3/4-in Phillips flat head concrete anchors.
These tools are required for the next stage of installation:
•
1/2-in hammer drill
•
3/16 x 3 1/2-in hammer drill bit, at minimum
•
Vacuum to clean inside the drilled holes for maximum thread
engagement
When drilling holes, be aware of buried conduit and pit drainpipes. Drill 3/16-in
holes, two inches minimum depth.
IR Repeater Installation
I NSTALLATION A SSEMBLY C OMPONENTS
• Infrared
sensor
• Mounting
collar
•
IR-100 control unit
•
IR flasher LED
• 9-12VDC
power supply
• Connection
cable
•
Flathead mounting screws
R EQUIRED T OOLS FOR I NSTALLATION
• Electric
drill
•
1-in hole saw to create a
•
1/16-in drill bit
