Operation | 25
7.0 Operation
Before placing into operation, follow the safety information in the
ETS-Lindgren Product Information Bulletin included with your
shipment.
If you are unfamiliar with the operation of the controller, see the
Model 2090 Series Multi-Device Controller Manual. A manual is included with
each positioning controller shipment and is also available for download from
www.ets-lindgren.com .
With the assembly of the turntable complete, the Model 2090 Series Multi-Device
Positioning Controller must be connected to the unit and power applied to both
the motor base and controller in order to continue. See the Model 2090 controller
manual for information on connecting the fiber optic cable.
Use the Model 2090 controller to check the clockwise (CW) and
counterclockwise (CCW) rotation in both directions by a few degrees. The
position in degrees increases (+) in the CW direction and decreases (-) in CCW
direction.
The turntable is calibrated in the factory to read out 360 degrees (plus or minus
1 degree) for one complete revolution. If the turntable is not within this range, the
unit can be re-calibrated using the instructions in Turntable Encoder Calibration
on page 28.
Editing Positioning Controller Configuration Parameters
Key Function
PARAM
To edit a configuration parameter:
• Press PARAM key to display the current parameter.
• Press PARAM key repeatedly to scroll through the
parameter list, displaying each parameter.
STEP (INC/DEC)
To scroll up or down the parameter list while viewing a parameter.
Reduces the effort necessary to scan through a long parameter list
using the PARAM key.
LIMIT/POSITION Press any of the LIMIT/POSITION selection keys to return the display
to that selection.
Press any of the remaining motion keys to return the display to the
current position and execute that motion.
Press the PARAM key again to return to the last displayed parameter
in the list, allowing easy transition between parameter adjustment and
device operation.
