Unpacking and Inventory
CAUTION
Do not handle the circuit board or touch components and boards inside the KXPA100
without anti-static protection! Doing so may damage sensitive components. See Preventing
Electrostatic Discharge Damage on page 5 for important information.
Before starting, check to be sure that you have the parts listed below.
KXAT100 Core Assembly Box E850594
ILLUSTRATION DESCRIPTION
QTY.
ELECRAFT
PART NO.
KXPA100 ATU PCB Assy
1
E850572
KXPA100 Front Panel for ATU
1
E850596
KXPA100 SO239 TMP Cable 4” Envelope E850584
ILLUSTRATION DESCRIPTION
QTY.
ELECRAFT
PART NO.
SO259 Connector with 4” (10.2 cm)
cable and TMP connector
1 E850600
Screw, Pan Head, Black 4-40,
5/16” (7.9 mm)
4 E700294
Nut, 4-40 with captive star washer
4
E700191
