CLIPS & COVERS NOT SHOWN AT THE
HEAD FOR CLARITY, BUT THEY MUST BE USED.
JDA 3/2002
C
DUAL CLIP
Fig. # 70
12"
SINGLE CLIP
6"
TYP.
L
L
C
DUAL CLIP
12"
SINGLE CLIP C
L
TYP.
L
C
6"
3"
3"
USING CLIPS AND COVERS
FOR STRUCTURAL BUTT GLAZED SYSTEMS
SECTION X C - TEMPORARY
GLAZING
PAGE 63
960 WALL
S108
SCREWS
H260 CLIP - 1" GLAZING
H261 CLIP - 1/4" GLAZING
TYP. SYSTEM
HEAD MEMBER
TYP. SYSTEM
SILL MEMBER
TYP. SYSTEM
EXT. COVER
#9635 - 2 9/16" B.M.
#9662 - 4 1/16" B.M.
#9663 - 4 13/16" B.M.
CUT TO FRAME D.L.O.
