Fig. # 30, Fig. # 29, Fig. # 28 – EFCO 960 Series User Manual

Page 42

SEE THE DOOR SHIPPING CARTON FOR

Anchor through the glazing pocket

are plumb and anchored.

Install the door stop after the jambs

sealant from door jamb to

with flat head screws.

Attach through the threshold

at the jambs with flat head screws.

by the closed door.

Apply a continuous bead of

door jamb.

The fastener will be concealed

FIG. # 30

9154/9155

FIG. # 29

INTERIOR

FIG. # 28

Locate the fastener 6" from the ends
and 24" on center maximum spacing.

pocket with flat head screws.

Anchor through the header glazing

SEE PAGES 10 THRU PAGE 12 FOR DOOR HEADER

by the closed door.

The fastener will be concealed

9154/9155

(CONT.)

PAGE 40

W138

DOOR INSTALLATION INSTRUCTIONS.

W138

JDA 10/2000

SECTION VI - DOOR FRAME INSTALLATION

AND DOOR JAMB IDENTIFICATION.
