PAGE 46
DOWN TO LOCK
FIG. # 41
STEP 1)
AND IN
See Fig. # 41 below.
UPWARD
The glass setting chair/block can be installed by rotating
upward and in, then push down to lock in place.
FIG. # 42
The setting chair
is parallel to the
horizontal surface
press down until locked into position.
See Fig. # 42 below.
when installed correctly.
LOCKING POINT
STEP 2)
To insure proper installation of the setting chair/block,
JDA 10/2000
SECTION VIII B -
SCREW SPLINE / SHEAR BLOCK
GLASS SETTING CHAIR ASSEMBLY INSTALLATION
INSTALLATION
