Step 6) step 7), Fig. # 20 – EFCO 960 Series User Manual

Page 36

background image

PAGE 34

(CONT.)

K150

FIG. # 20

K147

K170

assembling the units as shown in Fig. #20 above.

Assemble the units as shown in Fig. # 20 above.

STEP 6)

STEP 7)

9627

9610

9609

9608

Apply a butyl type sealant to the ends of all horizontals before

JDA 10/2000

SECTION IV - SHEAR BLOCK FABRICATION

SEALANT
ON ENDS

ON ENDS

SEALANT

See page 26 for sealant application guidance.

SEE PAGE 26

SEE PAGE 26
