Page 37: Is the same as the frame size, Fig. # 21 fig. # 22

is the same as the frame size.

HORIZONTAL COVER

The vertical covers are installed first. The length

The weep holes are located in the
underside and at the ends of the
intermediate horizontal cover,

See Fig. # 21 and # 22 below.

1" from the end and 1/4" in diameter.

FRAME

SIZE

1/4"

1/4" DIA. WEEP

The horizontal covers are installed after the vertical
covers. The cut length is D.L.O. - 1/16".

VERTICAL COVER
LENGTH = FRAME SIZE

LENGTH = D.L.O. - 1/16"

PAGE 35

FIG. # 21

FIG. # 22

JDA 10/2000

SNAP ON COVERS AND WEEP HOLES

SECTION V A -

SCREW SPLINE / SHEAR BLOCK

FABRICATION

HORIZONTAL COVER
