EFCO 960 Series - Manual (Page 27)

ASSEMBLED.
PAGE 25
(CONT.)
9613
9628
9616
NOTE:
1 9/16" BACK MEMBER SYSTEM
CANNOT BE SCREW SPLINE
MALE HALF OF
SPLIT MULLION
9625/9626
9611/9612
S108
S108
9627
9610
9609
S108 9628
FIG. # 7
9616
9613
Apply butyl type sealant
of horizontal and vertical
STEP 7)
at metal to metal joints
Snap together the assembled female and male units, then install
into the opening.
members. Refer to page 26.
9614/9615
JDA 10/2000
SECTION III - SCREW SPLINE FABRICATION
