4
2
For 03 function ONLY
Next, Drill 3/4" Hole
Through Interior Door
Face ONLY
Punch Marked
Holes
6
Wide Trim Door Preparation
Drilled Straight and Level
Note: All Holes Must Be
Door.
For 03 And 01
Pilot Hole Thru
Functions, Drill
Drill 3/8" Thru Holes
For Narrow Trim Refer to Pages 5 & 6.
FLOOR
5
For 03 function ONLY
Drill 1-1/2" Hole Through
Exterior Door Face ONLY
(1/4" up from center mark)
Mark 1/4" Up
from Center Mark
Pilot Hole
1/4"
(wide stile shown)
Mark Backplate Holes
Mark Centerhole
for 03 Function
1
Interior Door Face
(4 for Wide Stile)
3
PlaceTrim Unit to
Exterior Door Face.
Page 3
