6
CHAPTER 2: GETTING STARTED
After unpacking the scale, a small amount of preparation is required before the scale can be
used. Please refer to Figure 2-1 below as needed.
Power Jack
Serial Port
Figure 2-1: 304-BP Back Panel
Step 1. Position the scale in its area of intended use. Observe the following guidelines for
suitable location.
1. Choose a firm, stable floor or table.
2. Do not share an AC outlet with electrical noise producing equipment, such as
refrigeration units. This includes products with electrical motors and/or relays.
3. Do not place the scale in an area with changing ambient temperature and/or high
humidity.
4. Do not place the scale in an area prone to exposure to direct sunlight, wind, or dust.
5. Do not place the scale in an area with vibrating equipment.
Step 2. Install the AC Adapter.
1. After placing the scale in its area of use, locate the AC Adapter.
2. Connect the female end of the AC Adapter to the connector on the rear of scale, and
then plug the adapter into an AC outlet. Make sure that the AC voltage appearing
at the wall outlet matches the input voltage marked on the AC adapter.
NOTE: Six AA size alkaline batteries may also be used to power the scale. The battery
holder is located underneath the scale. Please observe the indicated polarity when
installing the batteries.
Step 3. If applicable, install the serial printer.
1. Connect the printer to the 304-BP‘s interface port using the optional serial cable.
2. Configure the printer’s communication parameters as detailed in Chapter 5.
Step 4. Push the ON/OFF key on the front panel to begin use.
