Page 54: Chapter 4, Chapter 4 using the usb playback console

background image

48

Chapter 4 Using the USB Playback Console

4.1

Recommended system requirements

Pentium® 4 2.4GHZ or above

Windows® 2000/ XP

DDR 256 MB

Graphic function must support DirectDraw

Audio card or built-in

Speaker

1 available USB2.0 port

4.2

Installing the USB Playback Console

To install the USB Playback Console:
1.

Place Installation CD into the CD-ROM drive. When the installation main screen appears, click
Install USB Playback Console and then follow the on screen instructions.

2.

Select the language you prefer.

3.

Click OK to install the application.

4.

Click Exit to close the installation main screen.

5.

You may now connect the DVR unit to PC by using USB cable.
