The startup sequence consists of sequentially asserting a number of signals to ensure proper
operation during user mode. These events are highlighted in Table 2 below.
Table 2: Startup Sequence Events
Stage Event
1 Assert Global Clock Enable
2 Assert I/O Enable
3 Assert Global Reset Enable
4 Assert Global Core Enable
5 Assert Config Done
6 Assert User Mode Enable
The shutdown sequence is very similar in nature to the startup sequence and essentially
entails deasserting these same signals in reverse order.
User Mode
: Once the device enters user mode, the design has been fully programmed
and the user can start sending and receiving data to/from the FPGA and performing intended
operations.
