Canon EOS 500QD - Manual (Page 63)

IV. OTHEh INFORMATION
Lens EF35 - 80 f/4 - 5.6 II EF80 - 200 f/4.5 - 5.6 USM
Angle of View Diagonal 63° - 30° 30° - 12°
Vertical 38° - 17° 17° - 7°
Horizontal 54° - 25° 25° - 10°
Optical Construction 8 elements in 8 groups 10 elements in 7 groups
Minimum aperture 22 - 32 22 - 27
Shooting distance 0.38 m - ~ 1.5 m -
Maximum magnification 35 mm 80 mm
0.12 (212 x328mm) 0.065 (366 X 546 mm)
80 mm 200 mm
0.25 (97 X 144 mm) 0.156(153x226 mm)
Diameter and number of
filters usable
52 mm, 1 52 mm, 1
Length
x
maximum diameter 61 X 65 mm 78 5 X 69 mm
Weight 170 g 260 g
The specifications of this product as weli as some externai features are subject
to change without notice, (Aii data based on Canon’s Standard Test Method)
C €
The CE Mark is a Directive conformity mark of
the European Community (EC)
63
