IV. O'mER INFORMATION
AF control system
® One-shot autofocus/stops on completion or
release on completion possible.
(D
Al Focus/One-shot autofocus, switches automati­
cally to Al Servo.
(D
Manual/with the focus mode switch on M, manual
focussing is possible.
AF working range EV 1.5-18 (at ISO 100 standard chart)
AF auxiliary light Automatically emitted.
Shutter Vertical-travel, focal plane shutter with all speeds
electronically controlled.
Shutter speed 1/2000-30 sec. and bulb. X-synchro on 1/90 sec.
(1/2 increment settings possible).
Self-timer Electronically controlled.
(with about 10 second delay)
Film Loading Automatic. After film loading and back cover closure,
the film automatically winds to the end of the roll and
stops.
Film Wind Automatic film wind:
® Single shot.
d) Continuous shooting (up to a maximum of about
one frame per second).
Rewind Automatic rewind. Rewind in mid roll possible.
Built-in flash Retractable type TTL automatic flash housed
in pentaprism. Bypass control system.
® Guide number/12 (ISO 100 m )
@ Recycling time approx. 2 sec.
® Flash coverage angle: cover the angle of view of
a 28mm lens.
Flash contacts X-sync contact, which connects directly to the acces­
sory shoe.
Batteries 2 lithium CR123A/DL123A batteries
Battery capacity check Can be checked by setting the command dial to any
setting outside the special mode zones.
Size 145 (W) X 92 (H) X 61.9 (D) mm
Weight About 355 g, or 365 g with the quartz date function.
(Body only and excluding two CR123A/DL123A lithi­
um batteries).
62
