Sony CCD-F33 - Manual (Page 8)

Identifying the Parts
A-5 [M]
MIC jack and DC OUT (microphone power
output) jack
Connect an external microphone.
The MIC jack accepts Sony "plug-in-power”
microphones and supplies power to them.
^ REC START/STOP button for low position
40
0
Hook for shoulder strap
Attach a shoulder strap.
Lens cap
Squeeze both sides of the lens cap to
remove it. Hook it to the grip strap so it won't
be lost or hanging loose while recording.
A-6
[Ml
To remove dust from inside the viewfinder
Detach the eyecup as illustrated and clean the
surface of the screen with a blower.
