2-16 SmartSwitch 6500 User Guide
Configuring the Switch Switch Installation and Setup
Figure 2-9 SmartSwitch 6500 connections for configuration
2.3.2 Backup/Redundancy Configuration
Backup/redundancy configuration consists of setting up the SmartSwitch 6500 to save configuration backup files used
by the master TSM/CPU and slave TSM/CPU (if any). The backup configuration file contains all configuration
changes made to the master TSM/CPU. For example, the backup file contains ELAN information, port configuration
changes, PVCs, and so on.
Note The backup file does not contain an image of the switch operating firmware. For
information on upgrading or replacing switch firmware, see Chapter 8, "Upgrades
and Firmware."
REDUNDANCY PWR
100 - 125V - 8.0A
200 - 250V - 4.0A
50/60 Hz
REDUNDANCY PWR
100 - 125V - 8.0A
200 - 250V - 4.0A
50/60 Hz
Terminal
Terminal
RJ-45 Port
Ethernet
RJ-45 Port
ATM
FAIL /MODE CPU
FAIL/ OK TSM
NO SYNC D ATA
123
4
6A-IOM-21-4
NO SYNC D ATA
123
4
6A-IOM-21-4
B
ATM
COM
ENET
POWER
ACTIVE
STANDBY
FAIL
ENET RDY
TX DATA
RX DATA
PS1 PS2 CSM TSM/CPU TSM 10 9 8 7 6 5 4 3 2 1
