2-4 SmartSwitch 6500 User Guide
Receiving the SmartSwitch 6500 Switch Installation and Setup
If the I/O module configuration is incorrect, contact the Cabletron Systems Global Contact Center immediately.
2.1.3 Check Accessory Carton Contents
Open the accessory carton and check that it contains the following items:
— 7-foot UTP cable terminated on both ends with RJ-45 connectors
— RJ-45 to 9-pin female adapter (labeled PC)
— Console cabling instruction sheet
— Diskettes containing switch software, MIB files, and release notes
— SmartSwitch 6500 Release Notes
— CD-ROM containing SmartSwitch ATM Administrator software for Windows 95/98, Windows NT, and Solaris
2.4/2.5
— CD-ROM containing the SmartSwitch 6500 User Guide, Reference Manual, related manuals, and Acrobat Reader
If any of these items is missing, contact the Cabletron Systems Global Contact Center immediately.
Table 2-1 I/O module ID numbers
Face Plate Number Physical Specification
IOM-21-4 155 Mbps OC-3/STM-1, MMF/SC (4 port)
IOM-22-4 155 Mbps STS-3c/STM-1, UTP-5/RJ-45 (4port)
IOM-29-4 155 Mbps OC-3/STM-1, SMF-IR/SC (1port) MMF/SC (3 port)
IOM-29-4-IR 155 Mbps OC-3/STM-1, SMF-IR/SC (4 port)
IOM-29-4-LR 155 Mbps OC-3/STS-1, SMF-LR/SC (4 port)
IOM-31-1 622 Mbps OC-12/STM-4, MMF/SC (1 port)
IOM-39-1 622 Mbps OC-12/STM-4, SMF-IR/SC (1 port)
IOM-39-1-LR 622 Mbps OC-12/STM-4, SMF-LR/SC (1 port)
IOM-67-4 45 Mbps DS-3, Coax/BNC (4 port)
IOM-77-4 34 Mbps E-3, Coax/BNC (4 port)
