Figure 2-5, Installing csm in slot 9 -8, Rotate ejector to lock in place – Cabletron Systems 6500 User Manual
Page 28: Metal backpanel card guides circuit card
2-8 SmartSwitch 6500 User Guide
Switch Installation and Assembly
Switch Installation and Setup
If you have a second CSM module, repeat steps 1 through 5.
Figure 2-5 Installing CSM in slot 9
Rotate ejector
to lock in place
COM
ENET
POWER
ACTIVE
STANDBY
FAIL
ENET RD
Y
TX D
ATA
RX D
ATA
Metal Backpanel
Card Guides
Circuit Card
