Specifications
Video camera
recorder
System.
Video recording system
Two rotary heads. Helical scanning
system
Audio recording system
Rotary heads, PCM system
Quantization: 12bits (Fs 32kHz,
stereo
Ì, stereo 2)
Video signal
NTSC color, EIA standards
Usable cassette
Mini DV cassette with logo printed
Recording/playback time
SP mode; 1 hour (DVM60)
LP mode: 1,5 hours (DVM60)
Fastforward/rewind time
Approx. 2 min. 30 s (DVM60) (using
with battery pack)
Approx. 1 min. 45 s (DVM60) (using
with AC power adaptor)
Viewfinder
Electric viewfinder (color)
Image device
CCD (Charge Coupled Device 1/3”)
Lens
Combined power zoom lens (Carl
,/eiss}, 150x (Digital), 12x (Optical)
Focal distance
f = 3/16 to 2 1 /8 inches (4.4 to
52.8 mm)
(lll/16tcTl97/8 inches(42to
504 mm) when converted into a 35
mm still camera)
F 1.8-2.8
Colour temperature
Auto
HOLD, INDOOR -4- 3,200K,
OUTDOOR 4 5,800K
Minimum illumination
3 lux at F 1.8
lliumination range
3 to 100,000 lux
Recommended illumination
More than 100 lux
LCD screen
2.5 inches measured diagonally
2x1 1/2 inches
(50.015x37.428 mm)
On-screen display
TNLCD/TFT active matrix method
Total dot number
180,000 (800 X 225)
Input and output
connectors
S video output
4'pin mini DIN
Luminnnco signal: 1 Vp-p, 75 ohms,
unbalanced, svnc negative
Chrominance signal; 0.286 Vp-p,
75 ohms, unbalanced
Audio Video/Headphones output
Special minijack
V: 1 Vp-p, 75 ohms, unbalanced,
sync negative
A: 327 mV (at output impedance
more than 47 kiiohms)
Output impedance with less than
2.2 kilohms/Stereo minijack
(0 3.5 mm)
DV input/output
4-pin connector
Connection
26-pin connector
LASER LINK
Video/Audio
IR special transmission system
Audio carrier
Lch: 4.3 MHz
Rch'. 4.8 MHz
General
Power requirements
7.2 V (battery insertion input)
8.4 V (26-pin connector)
Average power consumption
4.5 W during camera recording
using viewfinder
5.8 W during camera recording
using LCD screen
Operating temperature
32°F tol04°F (OX to 40X)
Storage temperature
to 140X (-20X to 60X)
Dimensions
Approx. 2 1/2 X 5 1/8 X
4 3/4 inches (61 x 129 x 118 mm)
(w/h/d)
Mass
Approx. 1 lb 2 oz.(530 excluding
the battery pack and cassette
Approx. 1 lb 6 02 (640 g) including
the battery pack NP-FIOO and
cassette DVM60
Microphone
Electret condenser microphone,
Stereo type
Speaker
Piezo-electric-speaker
Supplied accessories
See page 7.
AC power adaptor
Power requirements
100 to 240 V AC, 50/60 Hz
Power consumption
25 VV
Output voltage
DC OUT: 8.4 V, 1.8 A in operating
mode
Batterv charge terminal: 8,4 V, 1.4 A
in charge mode
Application
Sony battery pack NP-FlOO, NP-
F200, NP-F300 lithium ion type
Operating temperature
32"F to 104X (OX to 40X)
Storage temperature
~4X to 140“F (-20X to 60X)
Dimensions
Approx. 2 1/4x13/4x4 1/4
inches (57 x 44 x 107 mm) (w/h/d)
Mass
Approx. 7 02 (190 g)
Design and specifications are
subject to change without notice.
