G 760 48 3 CX T
Model
G-Series Explosion Proof Convection Heater
Temperature Rating
G Code kW ID Number ˚F ˚C (BTU)
160 1.6 T3A 356 180 5,500
180 1.8 T2A 536 280 6,150
320 3.2 T3A 356 180 11,000
360 3.6 T2A 536 280 12,300
400 4.0 T3A 356 180 13,600
450 4.5 T2A 536 280 15,350
760 7.6 T2A 536 280 25,930
900 9.0 T2A 536 280 30,700
Code Voltage Maximum kW Allowable
0 120 1.8
4 240 9.0
38 380 9.0
48 480 9.0
6 600 9.0
7 277 9.0
8 208 9.0
Code Phase
1 1Ш
3 3Ш (Not available in 120, 277V)
Control Combination
Code Contactor Transformer
Coil Secondary
None None
CX 24 Volt 24 Volt
CX* 120 Volt 120 Volt
Code Temperature Control
None
TB Thermostat 40 - 90˚F
Group B, C & D
T Thermostat Group C & D
50 - 90˚F
MODEL NUMBER BREAKDOWN
Note: Letter “B” will appear after phase code to indicate engineering version.
