After Working on Your Computer
After you have completed any replacement procedures, ensure you connect any external devices, cards, cables, etc. before turning on your computer.
1. Replace the computer cover. See Replacing the Computer Cover .
2. Connect any telephone or network cables to your computer.
3. If necessary, set the computer upright.
4. Connect your computer and all attached devices to their electrical outlets.
5. Turn on your computer.
Back to Contents Page
(SATA4) connector connector
16 serial ATA drive connector
(SATA5)
17 serial ATA drive
connector (SATA0)
18 battery socket
19 audio connector
(F_AUDIO)
20 PCI connector (PCI3) 21 PCI connector (PCI2)
22 PCI connector (PCI1) 23 PCI Express x1 connector
(PCIE_X1 2)
24 PCI Express x1 connector
(PCIE_X1 1)
25 PCI Express x16
connector (PCIE_x16)
26 audio connectors 27 one LAN and two USB
ports
28 CPU fan power 29 USB ports (2) 30 video connector (VGA)
NOTICE: To connect a network cable, first plug the cable into the network device and then plug it into the computer.
NOTICE: Ensure that none of the air vents of the system are blocked.
