Installing and Configuring Hardware

47

Figure 4-5. Removing the PERC H800 Adapter

5 Disconnect the data cables and battery cable from the PERC H700.

Remove any retention mechanism, such as a bracket screw, that might

be holding the PERC H700 in the system, and gently lift the controller

from the system’s PCI-E slot.

1 bracket screw

2 memory module

3 battery

4 Dirty Cache LED

5 PERC H800 Adapter

5

4

2

1

3

PERC7.2_UG.book Page 47 Thursday, March 3, 2011 2:14 PM
