126 Security Key and RAID Management
Securing Pre-Existing Virtual Disks
If an unsecured virtual disk was created on a controller, you can secure the
virtual disk as long as the following conditions are met:
• The controller has a security key present.
• All the physical disks in the virtual disk are SED.
Perform the following steps when securing a pre-existing virtual disk on a
secured controller:
1 During the host system bootup, press when the BIOS screen
is displayed.
The
Virtual Disk Management screen is displayed.
If there is more than one controller, the main menu screen is displayed.
2 Select a controller, and press .
The Virtual Disk Management screen is displayed for the selected controller.
3 Use the arrow keys to highlight the Disk Group number.
4 Press to display a menu of the available actions.
5 Highlight the Secure Disk Group option and press .
NOTE: If you select to secure a Disk Group, all virtual disks part of the Disk
Group are secured.
Importing or Clearing Secured Foreign Configurations and Secure Disk
Migration
Secured virtual disks created on a PERC H700 or H800 card can be migrated
to another PERC H700 or H800 card. A virtual disk secured with a local
security key different from the current controller security key cannot be
imported without authentication of the original passphrase used to secure
them.
When importing secured virtual disk(s) created with a different security key,
the secured foreign configuration(s) do not show in the Foreign
Configuration View screen. Follow the steps below to import or clear a
foreign secured virtual disk.
NOTE: If you are importing secured and unsecured virtual disks, you are prompted
to resolve the secured foreign configuration first.
