Removing and Installing Parts
133
8 Remove the two screws holding the floppy drive in the FlexBay drive cage.
9 Lift the floppy drive to separate it from the FlexBay drive cage.
10 Slide the FlexBay drive cage in the FlexBay slot till it snaps in place.
11 Replace the CD or DVD drive (see "Installing a CD or DVD Drive" on
page 143).
12 Reinstall the FlexBay drive insert (see "Replacing the FlexBay Drive Insert"
on page 136).
13 Replace the bezel (see "Replacing the Bezel" on page 124).
14 Replace the computer cover (see "Replacing the Computer Cover" on
page 165).
15 Connect your computer and devices to electrical outlets, and then turn
them on.
16 Check the system setup for the appropriate diskette Drive Option changes
(see "Entering System Setup" on page 172).
Installing a Floppy Drive
1 Follow the procedures in "Before You Begin" on page 101.
2 Remove the computer cover (see "Removing the Computer Cover" on
page 103).
3 Remove the bezel (see "Removing the Bezel" on page 123).
4 Remove the CD or DVD drive (see "Removing a CD or DVD Drive" on
page 142).
5 Remove the FlexBay drive insert (see "Removing the FlexBay Drive Insert"
on page 136).
6 Press the two spring clamps and slide out the FlexBay drive cage from the
front of the system (see "Removing a Floppy Drive" on page 131).
7 Place the floppy drive in the FlexBay drive cage and slide it towards the
cage notch to align the cage notch with the notch holes in the floppy drive.
