Installing System Components
45
Removing the Bezel
1 Unlock the bezel. See Figure 3-2.
2 Unlatch the left end of the bezel and rotate it away from the front panel.
3 Unhook the right end of the bezel and pull the bezel away from the system.
Figure 3-2. Installing and Removing the Optional Bezel
Installing the Bezel
1 Hook the right end of the bezel into the bezel slot on the right side of the system front plate
2 Rotate the other end of the bezel toward the front panel and press the bezel onto the panel to engage
the latch.
3 Lock the bezel.
1 key lock 2 bezel
2
1
