Jumpers and Connectors

System Board Connectors

See Figure 6-2 and Table 6-2 for the location and description of the system board connectors.

Figure 6-2.

System Board Connectors

Table 6-1.

System Board Jumper Settings

Jumper

Setting

Description

NVRAM_CLR

(default) The configuration settings in NVRAM are retained at system

boot.

The configuration settings in NVRAM are cleared at next
system boot.

PWRD_EN

(default) The password feature is enabled.

The password feature is disabled.

2

1

4
5
6
7

9

8

17

3

14

13

12

11

15

10

16

18

19
