Installing System Components 61
Figure 3-12. Removing and Installing the Heat Sink
Installing a Heat Sink
1 Place the new heat sink onto the system board.
2 Tighten the four captive screws of the heat sink. See Figure 3-12.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
