Using the System Setup Program 35
BMC LAN Configuration
The BMC LAN Configuration screen provides a way to configure BMC LAN
setting. Scroll to this item and press to view the following screen:
*1: [Dedicated-NIC][Shared-NIC]
Channel Number: Information only. Displays the Channel Number of BMC.
Channel Number Status: Information only. Displays the Channel Number
status of BMC.
BMC LAN Port Configuration: Port is routed to the management port on
the front of the C5000 chassis.
IP Address[xxx.xxx.xxx.xxx]: Enter an IP address in decimal in the form of
XXX.XXX.XXX.XXX (XXX less than 256 and in decimal only).
BIOS SETUP UTILITY
Server
LAN Configuration Set BMC LAN port to
dedicated-NIC or shared-
NIC
Channel Number
Channel Number Status:
BMC LAN Port Configuration
• IP Address
• Subnet Mask
• GateWay Address
• MAC Address
[01]
Status is OK
[Shared-NIC]*1


,

+,

F1
F10
ESC
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
