Installing System Components

75

Figure 3-23. Removing and Installing the Backplane Cables

7 Remove the two screws behind the power cord bracket attaching the

grounding cables to the chassis. See Figure 3-24.

Figure 3-24. Removing and Installing the Power Cord Bracket Screws

1

LAN connector

2

sideband connector

3

PMBus 2 connector

4

PMBus 1connector

5

PSU 1 connector

6

PSU 2 connector

1

2
3
4
5
6

2
